OverviewģDM Import for SolidWorks is a Shareware software in the category Graphics Applications developed by SYCODE.

TerrainCAD, our terrain generation, editing and modeling software, also uses the 3DM file format as its native file format. The OpenNURBS Initiative was founded by Robert McNeel & Associates in January 2000, with the sole purpose of providing CAD, CAM, CAE and computer graphics software users reliable methods for transferring 3D geometry between applications via the 3DM file format. The 3DM (3D Model) file format is the native file format of Rhinoceros, the NURBS modeling software from Robert McNeel & Associates.

# About - Display the 3DM Import for SolidWorks About boxģDM Import for SolidWorks comes with detailed documentation for each command as well as a tutorial to get you started in the shortest possible time. # Register - Register your copy of 3DM Import for SolidWorks # Help - Display the 3DM Import for SolidWorks help file

The '3DMImport' submenu consists of the following commands: It also adds a submenu to the SolidWorks menu called "3DMImport". The curves can be imported as a 3D Sketch in a part document, a 3D Sketch in an assembly document or 2D Curves in a drawing document.ģDM Import for SolidWorks is very easy to use as it adds new commands to SolidWorks. You can also import the polygon mesh as a 3D Sketch. it does not contain boundary edges) then 3DM Import for SolidWorks will create a closed body feature, otherwise an open surface will be created. 3DM Import for SolidWorks creates trimmed planar surfaces for each triangle/quad and knits them together to create a body. A polygon mesh in a 3DM file is comprised of a set of triangular/quad faces. This add-in gives SolidWorks the ability to import geometric data from 3DM files.ģDM Import for SolidWorks reads polygon mesh and curve data stored in 3DM files and imports it into SolidWorks. 3DM Import for SolidWorks is a Rhinoceros (.3dm) file import add-in for SolidWorks®.
